Bhyon 3.2
Designed by Giulio Cornia, the Bhyon becomes an enjoyable solution for those model aircraft enthusiasts who are looking for flying a full aerobatic program with a constant and relatively high speed in presence of soft wind conditions and thermals.
After adapting the original project to the needs of a molded production process, Glider_it’s Bhyon has a 3.2 meters wingspan and a thinner profile compared to the original one.
The latter combined with a generous wing surface gives to the model the perfect balance between speed and energy retention. Furthermore, thanks to a larger fuselage front section, an electric engine is easy to install.
Technical Data
| Unit of Measure | Value | |
|---|---|---|
| Wing span: | mm | 3.200 |
| Wing area: | dm2 | 77 |
| Fuselage length: | mm | 1.600 |
| Weight (OD, glider config.): | ∼kg | 5,8 |
| Weight (OD, extralight techn., glider config.): | ∼kg | 5,1 |
| Wing load (OD, extralight techn., glider config.): | g/dm2 | 66 |
| Wing airfoil: | n/a | Mod. HN 163 TA |
Technical Setup
| Suggested servos setup | Brand | Type | Max Thickness |
|---|---|---|---|
| elevator: | KST | BLS651 | 20 mm |
| rudder: | KST | BLS651 | 20 mm |
| ailerons: | KST | X10 | 10 mm |
| flaps: | KST | X10 | 10 mm |
| Suggested engine setup | ||
|---|---|---|
| Battery cell: | Lipo | 5s |
| Battery capacity: | mAh | 5.000 |
| Controller: | Castle Edge lite, Ah | 100 |
| Motor: | Leomotion | L4031-2550 finned 6,7:1 |
| FES*: | - | - |
| Propeller: | Leomotion | Carbon propeller 18x13 |
*Ask for more details.
